See the Wiki page for more information or watch the video on this new feature. Via Stitching runs as a post-process using an algorithm that identifies all Fills, Polygons and Power Planes attached to a specified net, then populates free areas of copper with stitching vias to connect the layers using the specified via and stitching pattern. It helps maintain low impedance connections and short return loops through the board structure for developing high-performance, electromagnetically 'quiet' PCBs. Of particular importance for RF and High Speed designs, the brand new Via Stitching feature applies a definable pattern of vias between layers where the copper areas overlap and share the same net. Complete list of Altium Designer updates Update 17: Updated plug-ins from release 10.890.23450 to 10.972.23595ĭate: 21 March 2012 Key highlights Via Stitching
